ASIC3抗体

ICC/IF analysis of Dorsal Root Ganglia (DRGs) neurons using GTX10354 ASIC3 antibody. Circle charts show the relative distribution of the three receptors among all DRG neurons. ASIC3 and P2X3 expression overlapped in only 4% of neurons, while some 35% of ASIC3-positive neurons also express TRPV1.
Red : Primary antibody
Green : P2X3 (green, A) or TRPV1 (green, B)

IHC analysis of rat Dorsal Root Ganglia (DRGs) of cisplatin-treated animals using GTX10354 ASIC3 antibody.
Dilution : 1:10

IHC analysis of human lung tissue using GTX10354 ASIC3 antibody. Normal (top panels A-C) and CF human lung sections (bottom panels D-F) were labeled with a specific antibody against ASIC3 (green channel) and the DNA-selective Hoechst dye (blue channel).
