alpha Adaptin抗体 [AC1-M11]

WB analysis of tissue and membrane enriched extract (30 ug) of Rat Brain (Lane 1), SH-SY5Y (Lane 2), U-87 MG (Lane 3), COLO 205 (Lane 4), PC-3 (Lane 5), MCF7 (Lane 6), NIH/3T3 (Lane 7) and A-431 (Lane 8) using GTX22807 alpha Adaptin antibody [AC1-M11].
Dilution : 2 μg/ml

ICC/IF analysis of SH-SY5Y cells using GTX22807 alpha Adaptin antibody [AC1-M11]. Panel e is a no primary antibody control.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : 4% paraformaldehyde
Permeabilization : 0.1% Triton X-100 for 10 minute
Dilution : 2 μg/ml in 0.1% BSA and incubated for 3 hours at room temperature

IHC-P analysis of human heart tissue using GTX22807 alpha Adaptin antibody [AC1-M11].
Left : Primary antibody
Right : Negative control without primary antibody
Antigen retrieval : heat induced antigen retrieval was performed using 10mM sodium citrate (pH6.0) buffer, microwaved for 8-15 minutes
Dilution : 1:20

ICC/IF analysis of NRK cells using GTX22807 alpha Adaptin antibody [AC1-M11].
